UGREEN CM400 M.2 SATA Enclosure – 5Gbps USB-C, NGFF B-Key (Aluminium)

The UGREEN CM400 (10903) is a compact aluminium enclosure that converts a B-Key or B+M Key M.2 SATA NGFF SSD into a portable USB-C external drive. It connects to a host computer via a 50cm USB-A to USB-C cable at up to 5Gbps, turning an existing or spare SATA-based M.2 drive into a fast, pocketable external storage device. Consequently, it suits users upgrading from an older SATA SSD, professionals needing a portable backup drive, and gamers expanding console storage on PS4, PS5, or Xbox.

---

How This Enclosure Differs from the UGREEN CM400 (10902) NVMe Model

If the installed drive is an NVMe PCIe SSD — such as the Samsung 970 EVO, WD Black SN750, or Kingston NV2 — the CM400 (10902) NVMe enclosure is required instead.

---

Technical Specifications

Enclosure & Interface

SSD Compatibility

Performance & Features

Physical

In the Box

---

Use Cases & Applications

Reusing a Spare M.2 SATA SSD After a Laptop Upgrade

Many laptop upgrades involve replacing a B+M Key SATA M.2 drive with a faster NVMe model. Rather than discarding the old drive, the CM400 (10903) houses it as a portable external SSD. At 5Gbps, a SATA III drive operating through UASP achieves sustained transfer rates of 400–500 MB/s — substantially faster than a traditional USB external hard drive. Furthermore, the aluminium enclosure’s passive cooling keeps the drive at safe operating temperatures during extended transfers.

Portable Backup and File Transfer

The CM400 (10903) suits any workflow requiring a compact, high-speed backup drive. A 500GB M.2 SATA SSD installed in the enclosure provides both the speed and the capacity to serve as a full system backup destination, a media transfer drive on location, or an archive drive for completed projects. The 50cm USB-A to USB-C cable connects directly to desktop computers, older laptops with USB-A ports, and USB-A hubs without requiring an adapter.

Console Storage Expansion

The CM400 (10903) works with PS4, PS5, and Xbox consoles as external storage via the USB-A to USB-C cable. SATA-based M.2 SSDs deliver significantly faster load times for games stored externally compared to conventional spinning hard drives. Additionally, the compact form factor means the enclosure sits unobtrusively alongside the console without cable management issues.

Mobile and OTG-Connected Storage

On Android smartphones and tablets that support USB OTG, the enclosure connects via a USB-C OTG adapter (such as the UGREEN US154), allowing direct file access from the M.2 SATA drive. This is particularly useful for photographers or videographers who need to offload files from a phone directly to a high-capacity SSD without a laptop intermediary.

---

Important Notes

• SATA NGFF only. The CM400 (10903) does not support NVMe PCIe SSDs. Drives such as the Samsung 970 EVO Plus and WD Black SN750 are NVMe and require the CM400 (10902) enclosure instead.
• New drives should be reformatted before first use. Format to exFAT for cross-platform compatibility between Windows and macOS.
• Only a USB-A to USB-C cable is included. A USB-C to USB-C cable is not provided. Users connecting to a USB-C-only laptop will need a separate USB-C to USB-C cable or adapter.
• Always eject safely from the host OS before disconnecting. Do not disconnect during active data transfer.
• Back up important data before installing a drive. UGREEN does not accept liability for data loss.

---

Compatible M.2 SATA SSD Brands and Models Include

Samsung 860 EVO M.2 SATA · Samsung 850 EVO M.2 SATA · WD Green M.2 2280 · WD Blue 3D NAND SATA · Crucial MX500 M.2 2280 · Crucial MX300 M.2 2280 · Kingston A400 M.2 2280 · Kingston UV500 M.2 2280 · ADATA SU800 · ADATA SL700 · DREVO D1
