Cisco Catalyst 2960X 24-Port PoE+ Managed Switch

The Cisco Catalyst 2960X WS-C2960X-24PS-L is a 24-port enterprise-grade managed switch built for businesses requiring advanced Layer 2 features with comprehensive security and network management capabilities. Moreover, it delivers 370W of PoE+ power with FlexStack-Plus stacking technology for scalable deployments. Consequently, this LAN Base model provides the performance and reliability that mid-sized organizations need for mission-critical infrastructure without the cost of full Layer 3 routing features.

Technical Specifications

Port Configuration

• 24x 10/100/1000 Mbps PoE+ ports (IEEE 802.3at/af compliant)
• 4x 1G SFP uplink ports
• 2x FlexStack-Plus module slots (modules sold separately)
• Total switching capacity: 104 Gbps
• Forwarding rate: 77.38 Mpps (wire speed)

Power over Ethernet

• Total PoE budget: 370W
• Per-port maximum: 30W (PoE+)
• PoE power management with priority settings
• Perpetual PoE support (maintains power during reboot)
• Fast PoE (reduces device boot time)
• Supports IEEE 802.3at (PoE+) and 802.3af (PoE)

Physical Specifications

• Dimensions: 445 × 445 × 44 mm (17.5 × 17.5 × 1.7 inches)
• Weight: 5.44 kg (12 lbs)
• Mounting: 19-inch rack-mountable (1U height)
• Cooling: Front-to-back or side-to-side airflow options
• Power: Dual redundant power supply support (RPS connector)
• Console: RJ-45 and Mini-USB console ports

Layer 2 Features

• MAC address table: 16,000 entries
• VLANs: 4,096 supported (1,005 active)
• Jumbo frames: Up to 9,216 bytes
• Link aggregation: 802.3ad LACP with up to 48 groups
• Spanning Tree: IEEE 802.1w RSTP, 802.1s MSTP, and Cisco PVST+
• FlexStack-Plus stacking (80 Gbps stack bandwidth)

Management & Security

• Cisco IOS Software with CLI and web-based management
• SNMP v1/v2c/v3
• 802.1X port-based authentication with MAB and Web Authentication
• SSH and SSL/TLS encryption
• Cisco TrustSec with Security Group Tags (SGT)
• Access Control Lists (IPv4 and IPv6)
• Port security with MAC address limiting
• DHCP snooping and Dynamic ARP Inspection (DAI)
• IP Source Guard
• RADIUS and TACACS+ authentication
• Storm control (broadcast, multicast, unicast)

Quality of Service

• 4 egress queues per port
• Traffic classification and marking
• Weighted Round Robin (WRR) scheduling
• Voice VLAN with auto-configuration
• Bandwidth control and rate limiting per port
• Trust boundary for IP phones

Stacking Capabilities

• FlexStack-Plus: Up to 8 switches per stack
• Stack bandwidth: 80 Gbps full duplex
• Hot-swappable stack modules
• Distributed forwarding across stack members
• Single IP management for entire stack

Availability Features

• Redundant power supply support (Cisco RPS 2300)
• FlexStack-Plus for stack resiliency
• Perpetual PoE during software upgrades
• IEEE 802.1ag Connectivity Fault Management
• UDLD (UniDirectional Link Detection)
• Fast link failure detection

Environmental & Compliance

• Operating temperature: 0°C to 45°C (32°F to 113°F)
• Storage temperature: -25°C to 70°C (-13°F to 158°F)
• Humidity: 10% to 85% non-condensing
• Altitude: Up to 3,000 meters (10,000 feet)
• MTBF: 352,053 hours
• Acoustic noise: 44.4 dBA at 25°C

Use Cases & Applications

Enterprise Campus Access Layer

The WS-C2960X-24PS-L serves as an ideal access layer switch in multi-building corporate campuses. Specifically, you can deploy it in wiring closets to connect employee workstations, IP phones, and wireless access points while using FlexStack-Plus to create resilient stacks that simplify management. Furthermore, the TrustSec capability enables consistent security policies across all access points regardless of physical location.

Healthcare Facilities

Medical centers benefit from the Catalyst 2960X’s ability to power nurse call systems, medical devices, IP phones, and wireless infrastructure throughout hospital floors. In particular, the 802.1X authentication ensures only authorized medical equipment connects to patient data networks. Meanwhile, Perpetual PoE maintains power to critical devices during scheduled maintenance windows.

Educational Institutions

Universities and schools can deploy the WS-C2960X-24PS-L in academic buildings to support high-density wireless deployments, VoIP communications, and networked classroom technology. Moreover, the switch’s QoS features prioritize video conferencing and distance learning applications. Additionally, FlexStack-Plus reduces the number of switches IT staff must individually manage across campus.

Financial Services Branches

Banks and financial institutions require the advanced security features that the Catalyst 2960X provides. Consequently, the switch supports secure VoIP for teller stations, powers security cameras, and connects ATMs while implementing strict access controls through TrustSec. Furthermore, the redundant power supply capability ensures continuous operation during business hours.

Hospitality and Hotels

Hotel properties can use the WS-C2960X-24PS-L to power guest room access points, corridor cameras, IP phones, and building management systems. In addition, the switch’s EnergyWise capabilities enable hotels to reduce energy consumption by powering down unused ports during low-occupancy periods.

Manufacturing and Warehouse Networks

Industrial environments benefit from the switch’s ability to connect production equipment, inventory management systems, and wireless barcode scanners. Similarly, the FlexStack-Plus technology provides network redundancy critical for maintaining uptime in time-sensitive manufacturing operations where network downtime directly impacts production output.
