Fanvil H6W Hotel IP Phone with Wi-Fi – Black

Fanvil H6W Hotel IP Phone with Wi-Fi – Black

Product Overview

The Fanvil H6W is a cost-effective WiFi hotel IP phone featuring dual-band WiFi 6 connectivity, an elegant design, and multiple programmable functions. Designed primarily for hospitality environments, it’s also suitable for shopping malls, hospitals, and supermarkets. The phone combines wireless flexibility with HD voice quality to enhance user experience while reducing deployment costs.

Display

• 3.5-inch IPS Color Screen (320×480 resolution)
• Customizable Background Image
• Slideshow Screensaver functionality
• Sleep Mode to reduce energy consumption
• MSG Indicator with red LED

WiFi Connectivity

Built-in Dual-Band WiFi 6:

• 2.4GHz: 802.11 b/g/n
• 5GHz: 802.11 a/n/ac/ax (WiFi 6 – 802.11ax)
• WiFi Encryption: WPA / WPA2-PSK / 802.1x EAP
• Factory Default SSID Configuration
• Eliminates cabling limitations for flexible room placement

SIP & Line Features

• 2 SIP Lines
• SIP Hotspot functionality
• HD Voice support
• Wideband ADC/DAC with 16KHz sampling

Programmable Keys & Interface

• 21 Keys Total:
  • 12 Standard phone digit keys
  • 5 Programmable DSS/Soft keys for hotel services
  • 3 Function keys (Up/Down/Mute)
  • 1 Hands-free key

Customizable Hotel Services:

• Custom hotel service numbers and icons
• Pre-configured services: Front desk, Room service, Housekeeping, Switchboard, etc.
• Intelligent DSS Keys (speed dial key)

Audio Capabilities

Codecs:

• Narrowband: G.711A/U, G.729AB, G.723.1, G.726, iLBC
• Wideband: G.722, Opus

Audio Features:

• Full-duplex hands-free speakerphone with AEC (Acoustic Echo Cancellation)
• Voice Activity Detection (VAD)
• Comfort Noise Generation (CNG)
• Background Noise Estimation (BNE)
• Noise Reduction (NR)
• Automatic Gain Control (AGC)
• Packet Loss Concealment (PLC)
• Dynamic Adaptive Jitter Buffer
• DTMF: In-band, Out-of-Band DTMF-Relay (RFC2833) / SIP INFO
• VQM voice quality monitoring

Network & Connectivity

Ethernet:

• 10/100 Mbps Ethernet
• Single RJ45 Port for network connection
• Integrated PoE support

Network Features:

• IP Mode: IPv4/IPv6/IPv4&IPv6
• IP Configuration: Static / DHCP / PPPoE
• Network Access Control: 802.1x
• VPN: L2TP / OpenVPN
• VLAN: 802.1P/Q
• QoS, LLDP support
• RTCP-XR (RFC3611), VQ-RTCPXR (RFC6035)

Call Features

• Call out / Answer
• Mute / Unmute
• Call Hold / Resume
• Speed Dial / Redial
• Hot Line
• Voice Message
• Distinctive ring
• Multicast
• Dial plan
• Web dial
• Action URL / Active URI

Protocols

• SIP v1 (RFC2543), v2 (RFC3261) over UDP/TCP/TLS
• RTP/RTCP/SRTP
• STUN, DHCP, IPv6
• PPPoE, L2TP, OpenVPN
• SNTP, FTP/TFTP
• HTTP/HTTPS, TR-069

Deployment & Management

• Auto-provisioning: FTP/TFTP/HTTP/HTTPS/DHCP OPT66/SIP PNP/TR-069
• Web Management Portal
• Web-based packet dump
• Configuration export/import
• Firmware upgrade capability
• Syslog support

Physical Specifications

Ports:

• RJ9 Port x1: Handset
• RJ45 Port x1: Network
• USB-A Port x1: Guest device charging (no additional converters needed)

Power:

• DC 5V 2A (optional external adapter)
• PoE (Power over Ethernet) integrated
• Power Consumption (PoE): 1.56 ~ 8.29W
• Power Consumption (Adapter): 0.97 ~ 6.08W

Installation:

• Desktop stand with 30° angle
• Color: Black / White

Dimensions:

• Device (Desktop Stand 30°): 221 x 127.5 x 70.5 mm
• Gift Box: 190 x 228 x 95 mm
• Outer Carton: 495 x 476 x 210 mm (10 units per carton)

Weight:

• Net Weight per Carton: 8.15 kg
• Gross Weight per Carton: 9.10 kg

Environmental:

• Working Temperature: 0~45℃
• Working Humidity: 10~95%

Package Contents

• Handset (RJ9) x1
• Standard RJ9 Handset Cord x1
• 1.5M CAT5 Ethernet Cable x1

Platform Compatibility

• Compatible with major VoIP platforms and hotel management systems
• Works with Asterisk, Broadsoft, 3CX, and other SIP-based platforms
