Detailed Specifications

Cable Construction

• Type: 4-pair Unshielded Twisted Pair (UTP)
• Conductor: 24 AWG Bare Copper (solid copper, not CCA)
• Insulation: HD-PE (High-Density Polyethylene)
• Jacket: PVC UL94V-0 (flame-retardant)
• Heat Resistance: 60°C minimum
• Flame Rating: VW-1 (UL) / FT-1 (CSA) standards

RJ-45 Connector Quality

• Plating: 30μ" Gold plated (excellent corrosion resistance)
• Contact Material: Phosphor Bronze
• Housing: Polycarbonate (PC) UL94-V-0
• Temperature Range: -10°C to 80°C
• Dielectric Withstanding: 500V AC
• Insulation Resistance: 35M Ohm max
• Durability: 750 matching cycles
• Tensile Strength: 20 lbs (89N) minimum
• Rating: 250V AC, 2A max

Applications Supported

✓ 10BASE-T / 100BASE-TX / 1000BASE-T (Gigabit Ethernet) ✓ 100VG-AnyLAN (IEEE 802.12) ✓ 550 MHz Broadband Video ✓ Voice, T1, ISDN ✓ 155/622 Mbps ATM ✓ Power over Ethernet (PoE) - Perfect for your U6+ AP!

Certifications & Compliance

• UL 444 (Copper conductor)
• UL 758 / Style 2835
• UL 1581 (Test standard)
• TIA/EIA-568C.2 compliant (verified by ETL)
• CUL listed
• RoHS compliant (environmentally friendly)

Why This Cable Is Quality

Key advantages over cheaper alternatives:

1. Bare Copper Conductor - Not copper-clad aluminum (CCA), ensuring:
   • Better conductivity
   • Lower resistance
   • Reliable PoE power delivery
   • Longer lifespan
2. 30μ" Gold Plating - Superior to standard connectors:
   • Better corrosion resistance (important in humid climates)
   • Maintains signal integrity over time
   • Reliable connections
3. High Durability - 750 insertion cycles rated
4. Full Compliance - Meets/exceeds TIA/EIA-568C.2 standards

Perfect for U6+ Deployment

This cable is ideal for connecting your Ubiquiti U6+ access points because:

• ✓ Fully supports PoE (the U6+ requires 802.3af PoE)
• ✓ Gigabit Ethernet capable
• ✓ Quality copper ensures stable power delivery
• ✓ Multiple lengths available for flexible installation
