APC 2000VA Easy UPS Rackmount (SRV2KRIRK)

The APC 2000VA Easy UPS Rackmount (SRV2KRIRK) delivers reliable power protection for network equipment, servers, and telecommunications infrastructure in rack-mounted environments. This line-interactive UPS system provides 2000VA/1600W of power capacity with automatic voltage regulation to safeguard critical IT equipment from power disturbances. Designed for small to medium-sized businesses and branch offices, it combines essential backup power features with space-efficient 2U rackmount design.

Technical Specifications

Power Capacity

• Output Power: 2000VA / 1600W
• Topology: Line-Interactive with Automatic Voltage Regulation (AVR)
• Waveform: Simulated Sine Wave (on battery)
• Input Voltage Range: 160-290V AC
• Output Voltage Regulation: ±10% (on battery mode)

Battery & Runtime

• Battery Type: Maintenance-free sealed lead-acid
• Typical Recharge Time: 8 hours to 90% capacity
• Battery Replacement: Hot-swappable without powering down connected equipment
• Audible Alarm: Multi-condition alerts for battery status and power events

Physical Design

• Form Factor: 2U 19-inch rack-mountable chassis
• Dimensions: 438mm (W) x 88mm (H) x 660mm (D)
• Weight: Approximately 26 kg (fully equipped)
• Operating Temperature: 0°C to 40°C
• Relative Humidity: 0-95% non-condensing

Connectivity & Outlets

• Output Connections: IEC 320 C13 receptacles
• Communication Ports: USB for local management
• Management Options: Compatible with PowerChute software for automated shutdown and monitoring
• Network Card Slot: Optional SNMP/Web management card support

Protection Features

• Surge Protection: Integrated surge suppression for connected equipment
• Input Circuit Breaker: Overload protection with manual reset
• Voltage Regulation: Automatic boost/trim without battery drain
• Transfer Time: 2-4ms typical (fast enough for IT equipment)

Compliance & Standards

• Safety Certifications: IEC 62040-1, EN 62040-1
• EMC Compliance: IEC 62040-2, EN 62040-2
• Warranty: Standard manufacturer warranty coverage

Use Cases & Applications

Server Room Protection

The SRV2KRIRK provides comprehensive power backup for small server installations, protecting file servers, domain controllers, and database servers from unexpected shutdowns that could cause data corruption. The 2U design fits standard 19-inch racks alongside the equipment it protects.

Network Infrastructure Support

Network administrators deploy this UPS to maintain continuous operation of core switches, routers, firewalls, and wireless controllers during power events. Additionally, the AVR functionality protects sensitive networking gear from voltage sags that commonly occur during high-demand periods or grid instability.

Telecommunications Equipment

Voice-over-IP phone systems, SIP servers, and call center infrastructure benefit from uninterrupted power delivery, preventing dropped calls and maintaining business continuity. The cold start feature proves particularly valuable for telecommunications applications requiring emergency system activation.

Branch Office Deployments

Remote office locations often experience less stable power conditions than headquarters facilities. This UPS model addresses those challenges while providing centralized monitoring capabilities through optional network management cards, allowing IT teams to oversee distributed power protection infrastructure.

Security System Backup

Surveillance recording servers, access control systems, and IP camera infrastructure require continuous operation for facility security. The APC Easy UPS ensures these critical security systems remain operational during brief power interruptions, maintaining facility protection and recording capabilities.
