Hikvision DS-3E0108D-E – 8-Port Fast Ethernet Unmanaged Plastic Desktop Switch
The Hikvision DS-3E0108D-E Kenya listing covers an 8-port Fast Ethernet unmanaged Layer 2 desktop switch in a light ABS plastic housing. Specifically, it provides 8 × 10/100 Mbps RJ45 ports with auto-negotiation and auto MDI/MDI-X. As a result, it connects PCs, printers, IP phones, and low-bitrate cameras without any setup.
Meanwhile, its 1.6 Gbps switching capacity lets all eight ports run at full 100 Mbps at the same time. In addition, store-and-forward switching checks each frame before passing it on, which in turn limits corrupted traffic. Notably, this is a data-only switch with no PoE output, so connected devices need their own power.
Furthermore, the compact white plastic shell sits neatly on a desk, shelf, or TV unit. Its fan-free design keeps it silent in homes and small offices. It runs on a 5 VDC, 0.6 A adapter, so its power draw stays low. For more networking and surveillance products, browse our full Hikvision catalogue.
Technical Specifications
| Specification | Details |
|---|---|
| Model | DS-3E0108D-E |
| Product Type | 8-Port Fast Ethernet Unmanaged Layer 2 Desktop Switch |
| Ports | 8 × 10/100 Mbps RJ45 ports |
| Port Type | RJ45, auto-negotiation, auto MDI/MDI-X |
| PoE | Not supported (data-only, non-PoE switch) |
| Management | Unmanaged (plug-and-play) |
| Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3x |
| Forwarding Mode | Store-and-forward switching |
| Switching Capacity | 1.6 Gbps |
| Packet Forwarding Rate | 1.1904 Mpps |
| MAC Address Table | 1 K |
| LED Indicators | Yes |
| Shell | ABS plastic, white, fan-free design |
| Installation | Desktop |
| Power Supply | 5 VDC, 0.6 A max. (external adapter) |
| Operating Temperature | 0°C to 40°C |
| Storage Temperature | -40°C to 70°C |
| Operating Humidity | 10% to 90% (non-condensing) |
| Storage Humidity | 5% to 90% (non-condensing) |
| Dimensions (W × D × H) | 124 mm × 59 mm × 23.2 mm |
