Epson M15140

Epson M15140 A3+ Monochrome Wi-Fi Duplex All-in-One Ink Tank Printer

The Epson M15140 is an A3+ monochrome ink tank multifunction printer designed for offices that regularly produce large-format documents at scale. It handles print, scan, and copy up to A3+ size, supported by a high-capacity paper feed system and Epson’s heat-free PrecisionCore technology. Furthermore, it targets workgroups and small-to-medium businesses that need A3 output without the running cost of a mono laser device.

---

Technical Specifications

Printing

• Print Technology: PrecisionCore heat-free printhead, pigment ink
• Nozzle Configuration: 800 nozzles (black), bi-directional
• Print Resolution: 4,800 × 1,200 DPI
• Minimum Droplet Size: 3.8 pl
• Draft Speed (A4): Up to 32 ppm
• ISO 24734 Speed (A4): Simplex: 25 ipm / Duplex: 16 ipm
• ISO 24734 Speed (A3): Simplex: 13.5 ipm / Duplex: 10 ipm
• First Page Out (A4 Simplex): 5.5 seconds / Duplex: 11 seconds
• Printer Language: ESC/P-R, ESC/P Raster
• Automatic Duplex: Yes (A4 and A3, plain paper)

Scanning

• Scanner Type: Flatbed Colour Image Scanner (CIS)
• Optical Resolution: 1,200 × 2,400 DPI
• Maximum Scan Area: 297 × 431.8 mm (A3)
• Flatbed Scan Speed: 5 sec (A4 black, 200 DPI) / 10 sec (A4 colour, 200 DPI)
• ADF Scan Speed (Simplex): 26 ipm (black) / 9 ipm (colour) at 200 DPI
• ADF Scan Speed (Duplex): 11.5 ipm (black) / 6 ipm (colour) at 200 DPI
• Scanner Bit Depth: 48-bit input / 24-bit output (colour); 16-bit input / 8-bit output (greyscale)
• Output Formats: BMP, JPEG, TIFF, multi-TIFF, PDF, PNG
• Software: Epson ScanSmart

Copying

• Copy Speed (A4 Flatbed Simplex): Up to 23 ipm
• Copy Speed (A4 ADF Simplex): Up to 22.5 ipm / Duplex: 15.5 ipm
• Maximum Copies (Standalone): 999
• Reduction/Enlargement: 25–400%
• Maximum Copy Resolution: 600 × 600 DPI
• Maximum Copy Size: A3 / Ledger
• ADF Duplex Copy: Yes (A4 and A3, plain paper)

Paper Handling

• Number of Trays: 3
• Cassette 1: 250 sheets A4/A3, plain paper (80 g/m²)
• Cassette 2: 250 sheets A4/A3, plain paper (80 g/m²)
• Rear Slot: 50 sheets A4/A3, plain paper (80 g/m²)
• Total Input Capacity: 550 sheets
• Output Tray Capacity: 125 sheets
• ADF Capacity: 50 sheets (64–95 g/m²)
• Maximum Paper Size: 329 × 6,000 mm
• Supported Formats: A3+, A3, A4, A5, A6, B4, B5, B6, Letter, Legal, C4/C6/DL envelopes, 10×15 cm, 13×18 cm, 20×25 cm
• Print Margin: 3 mm (top, left, right, bottom via driver custom settings)

Ink & Yield

• Ink Technology: Pigment black
• Replacement Bottle Yield: Up to 7,500 pages (ISO 24711/24712 methodology)
• Ink Bottle Order Code: C13T06G198
• Maintenance Box: C12C934601

Connectivity

• USB: High-speed USB 2.0
• Wired Network: Ethernet (TCP/IPv4, TCP/IPv6)
• Wireless: Wi-Fi IEEE 802.11 a/b/g/n, Wi-Fi Direct (up to 8 devices)
• Network Management: SNMP, HTTP, DHCP, BOOTP, APIPA, PING, DDNS, mDNS, SNTP, SLP, WSD, LLTD
• Mobile & Cloud Printing: Epson iPrint, Epson Email Print, Remote Print Driver, Scan-to-Cloud, Apple AirPrint, Mopria Print Service

Display & Interface

• Control Panel: 6.85 cm (2.7″) colour LCD touchscreen

Operating System Compatibility

• Windows: XP / Vista / 7 / 8 / 8.1 / 10 (32/64-bit); Windows Server 2003–2016
• macOS: Mac OS X 10.6.8 or later (through macOS 10.13.x)

Physical

• Dimensions: 515 × 500 × 350 mm (W × D × H)
• Weight: 20.2 kg
• Country of Origin: Philippines

Power

• Operating: 19.0 W
• Standby: 9.1 W
• Sleep: 0.8 W
• Power Off: 0.2 W
• Supply Voltage: AC 220–240 V / 50–60 Hz

Noise

• Sound Power: 6.7 B(A) / Sound Pressure: 52 dB(A) (plain paper default)

Warranty

• Standard: 1 year carry-in or 350,000 pages (whichever comes first), printhead included

---

Use Cases

The Epson M15140 suits offices where A3 output is a routine requirement rather than an occasional need. Engineering, architecture, and design firms use it for technical drawings and plan printouts that exceed A4 dimensions. Finance and legal departments benefit from the A3 spreadsheet and ledger printing capability alongside automatic duplex, which reduces paper consumption on multi-page reports. The 50-sheet A3 ADF supports batch scanning of large-format contracts and reference documents into searchable PDFs via Epson ScanSmart. However, organisations that also require colour output should consider the Epson L6570 or a colour A3 alternative, as the M15140 handles black-and-white printing only. For high-volume mono environments replacing an ageing laser device, the M15140 offers a lower per-page cost and substantially reduced energy draw without sacrificing throughput.
