Hikvision DS-2CE72KF0T-LFS(2.8MM) — 3K ColorVu Smart Hybrid Light Fixed Turret Camera
The Hikvision DS-2CE72KF0T-LFS(2.8MM) is a 3K (2960 × 1665) outdoor-rated turret camera built around Hikvision’s ColorVu technology, delivering 24/7 full-colour imaging at sharper detail than standard 2 MP cameras. A wide F1.0 aperture keeps footage in colour down to 0.001 Lux, while Smart Hybrid Light automatically blends IR and white light (up to 40 m each) for reliable night performance. Housed in an IP67-rated metal-and-plastic enclosure, it’s built for outdoor exposure, and includes a built-in microphone for audio-over-coaxial recording. The camera supports four switchable signal formats (TVI/AHD/CVI/CVBS) over a single coaxial cable, making it a straightforward fit for existing analogue DVR setups.
Key Features
- 3K resolution (2960 × 1665) — sharper detail than standard 2 MP ColorVu cameras
- 24/7 ColorVu imaging — F1.0 aperture keeps footage in full colour day and night, down to 0.001 Lux
- Smart Hybrid Light — automatic IR + white light switching, up to 40 m range for both
- IP67 water and dust resistance — rated for outdoor installation
- Built-in microphone with audio over coaxial cable for on-site sound capture
Technical Specifications
| Specification | Details |
|---|---|
| Model | DS-2CE72KF0T-LFS(2.8mm) |
| Image Sensor | 3K CMOS |
| Signal System | PAL/NTSC |
| Resolution | 2960 (H) × 1665 (V) |
| Frame Rate | TVI: 3K@20 fps, 4 MP@25/30 fps, 1080p@25/30 fps; AHD: 5 MP@20 fps, 4 MP@25/30 fps; CVI: 4 MP@25/30 fps; CVBS: PAL/NTSC |
| Min. Illumination | 0.001 Lux @ (F1.0, AGC ON); 0 Lux with white light on |
| Shutter Time | PAL: 1/25 s to 1/50,000 s; NTSC: 1/30 s to 1/50,000 s |
| Lens | 2.8 mm fixed focal lens |
| Field of View | 2.8 mm — Horizontal: 110°, Vertical: 60°, Diagonal: 143° |
| Lens Mount | M12 |
| Light Alarm | Solid Light Alarm (White Light) |
| Day & Night | ICR |
| Wide Dynamic Range | Digital WDR |
| Angle Adjustment | Pan: 0°–360°, Tilt: 0°–75°, Rotation: 0°–360° |
| Microphone | Built-in — pickup radius up to 5 m |
| Supplement Light Type | Smart, IR, White Light |
| Supplement Light Range | IR: up to 40 m; White Light: up to 40 m |
| White Light Mode | Auto/Off |
| Image Mode | STD / HIGH-SAT / HIGHLIGHT |
| AGC | Yes |
| Day/Night Mode | Auto / Color |
| White Balance | Auto / Outdoor / Global / Manual |
| AE (Auto Exposure) Mode | DWDR, BLC, HLC, Global, HLS |
| Noise Reduction | 2D DNR |
| Function | Brightness, Smart IR, Sharpness, Anti-Banding, AGC |
| Video Output | Switchable TVI/AHD/CVI/CVBS |
| Audio In | Built-in mic |
| Protection | IP67 (water and dust resistant) |
| Material | Enclosure: Plastic; Main body: Metal |
| Power Supply | 12 VDC ± 25%, max. 5.2 W |
| Dimensions | Ø 109.98 mm × 98.27 mm (Ø 4.33″ × 3.87″) |
| Weight | Approx. 320 g (0.71 lb.) |
| Operating Conditions | -40 °C to 60 °C (-40 °F to 140 °F); Humidity 90% or less (non-condensing) |
| Communication | HIKVISION-C |
Best Suited For
- Outdoor perimeters and gates — compound walls, driveways, and entrances in Kenyan homes where an IP67 rating is essential for weather exposure
- Retail shops and small businesses — exterior entrances and loading areas where 3K resolution helps identify faces, vehicles, or number plates more clearly than standard 2 MP footage
- Analogue DVR upgrades — properties already running TVI/AHD/CVI/CVBS systems that want higher-resolution outdoor ColorVu imaging while keeping their existing coaxial cabling and recorder
