Dlink

Port Configuration:

• 8 x Gigabit PoE ports (ports 1-8)
• 2 x Gigabit uplink ports (ports 9-10)
• All ports support auto MDI/MDIX and auto-negotiation

Power over Ethernet:

• Total PoE budget: 96 watts
• Supports IEEE 802.3af/at PoE standards
• Enables powering of PoE-capable devices like wireless APs and IP cameras without additional power adapters

Key Feature - Extended Range:

• Supports transmission distances up to 250 meters (when using Cat5e or Cat6 cables)
• Ideal for flexible installation of wireless access points and surveillance solutions in remote locations

Performance:

• Switching capacity: 20 Gbps
• Forwarding rate: 14.88 Mpps at 64-byte packets, 148,800 pps at 100 bytes, and 1,488,000 pps at 1000 bytes
• IEEE 802.3x Flow Control to prevent data loss

Operating Modes (via DIP switch):

1. Extend Mode: Ports 1-8 support 250m long-distance power supply
2. VLAN Mode: Isolates ports 1-8 to suppress network storms and improve performance
3. QoS Mode: Customizes application priority for smoother video/monitoring transmission
4. PoE Mode: Automatically detects power-receiving ports, finds dead devices, and powers them off/restarts them

Design:

• Fanless device (quiet, eco-friendly operation)
• Compact dimensions: 184 x 94 x 27mm
• Weight: 0.95kg
• Operating temperature: 0-40°C
• 6KV lightning protection

Key Features & Benefits

• 250 W Gigabit PoE+ Across All 24 Ports: The DGS-F1026P-E supports both IEEE 802.3at and IEEE 802.3af PoE, with a total power budget of 250 W and up to 30 W per port — eliminating the need for additional power sources on connected devices. Dlink-me This budget comfortably supports a dense mix of PTZ cameras, dual-band access points, and IP phones drawing simultaneously from the same switch.
• 250 m Long-Range PoE on Ports 1–8: Extend mode enables ports 1–8 to supply 802.3af/at PoE and data connectivity on cables up to 250 m long, using Cat 5e or Cat 6 cabling. Dlink-me Consequently, cameras and access points installed at the perimeter of a building or across a car park can receive both power and data over a single cable run, without the need for intermediate switches or media converters.
• DIP-Switch Operating Modes: Using the DIP switch, administrators can change the working mode between Extend, VLAN, QoS, and PoE — with no software, login credentials, or configuration interface required. Dlink-me This makes the DGS-F1026P-E practical for installers who need site-specific network behaviour set up quickly at the switch itself, rather than through a management interface.
• AI PoE Watchdog for Automatic Device Recovery: The PoE mode automatically detects an unresponsive PoE device and reboots it to restore normal operation. Dlink This reduces the need for on-site technician visits to manually restart frozen IP cameras — particularly useful in remote or difficult-to-access installation points.
• 6 kV Surge Protection and Fanless Operation: Built-in 6 kV lightning protection reduces the risk of equipment damage from electrical surges, and the fanless design runs reliably and quietly while saving energy. Dlink-me Additionally, wire-speed store-and-forward switching minimises transmission of bad network packets without throttling throughput.
