UGREEN DisplayPort to HDMI Female Converter 1080P (Black) – MM137 / 40362

The UGREEN DisplayPort to HDMI female converter connects a DisplayPort-equipped laptop, desktop, or graphics card to an HDMI monitor, projector, or HDTV at 1080P@60Hz. Unlike a cable, this compact dongle accepts any standard HDMI cable already connected to the display — making it a practical solution for users who want to retain their existing HDMI cables while gaining a DisplayPort connection. Plug-and-play operation requires no drivers on Windows, macOS, or Linux.

---

Technical Specifications

Connectivity

• Input: DisplayPort Male (supports DP, DP++, DisplayPort++)
• Output: HDMI Female
• Direction: Unidirectional — DisplayPort to HDMI only (HDMI to DP is not supported)
• Conversion: Active IC chipset

Video Performance

• Maximum resolution: 1920×1080 (1080P Full HD) @ 60Hz
• Display modes: Mirror and Extended desktop

Audio

• Transmission: Simultaneous with video
• Formats: Uncompressed LPCM; 7.1, 5.1, and 2-channel audio

Build & Physical

• Connector housing: ABS plastic (Black)
• Connector finish: 24K gold-plated
• Internal wiring: Tinned copper with aluminium foil shielding
• Cable length: 0.25m (25cm)
• Colour: Black

In the Box

• 1× UGREEN DP Male to HDMI Female converter
• Note: An HDMI cable is required separately and is not included

Buyer Note: The MM137 40362 supports a maximum resolution of 1080P@60Hz. It is not capable of 4K output. For 4K@30Hz, the UGREEN MM137 40363 (same form factor, higher bandwidth) is the recommended upgrade. Confirm your display’s maximum resolution before purchase.

---

Compatible Devices

Source (DisplayPort output — DP, DP++, or DisplayPort++):

• Desktop PCs and workstations with a full-size DisplayPort output
• Laptops with a DisplayPort port
• Graphics cards: AMD Radeon series (including Eyefinity support) and Nvidia GeForce series with DP outputs
• HP EliteBook, Dell OptiPlex, Lenovo ThinkPad, and similar DP-output business machines

Display (HDMI input — via HDMI cable, sold separately):

• HDMI monitors (1080P panels)
• HDTVs and smart TVs with HDMI input
• Projectors with HDMI input
• Conference room displays and classroom projectors

---

Use Cases

Connecting a DP desktop to an HDMI monitor — Many budget and mid-range monitors ship with only an HDMI cable. The MM137 40362 allows a DisplayPort graphics card output to connect directly to that HDMI monitor cable without replacing it or buying a new cable.

Office and conference room presentations — Plug the adapter into a laptop or desktop DisplayPort port and connect the room’s existing HDMI cable to the projector or display instantly. The latching connector keeps it secure during the presentation.

AMD multi-monitor Eyefinity setup — Use the converter as a third or fourth display output on an AMD Radeon GPU alongside other DP and HDMI outputs, extending the desktop across multiple screens in an Eyefinity configuration.

Home entertainment and media streaming — Connect a desktop PC or HTPC to an HDTV via the room’s existing HDMI cable. Both video and 7.1 surround audio are carried through the single connection, removing the need for a separate audio output cable.
