MikroTik hAP Lite RB941-2nD-TC

The MikroTik RB941-2nD-TC is a compact wireless access point and router designed for home networks and small office environments requiring reliable connectivity. This affordable device combines 2.4 GHz wireless capabilities with four Ethernet ports, providing essential networking features for basic internet sharing and wireless coverage. Home users and small businesses gain access to professional RouterOS features without the complexity of enterprise-grade equipment.

Technical Specifications

Hardware Architecture

• CPU: Qualcomm Atheros QCA9533 at 650 MHz
• Memory: 32 MB RAM
• Storage: 16 MB flash memory
• Chipset: Single-chip design for wireless and routing

Wireless Capabilities

• Frequency: 2.4 GHz only
• Standards: 802.11b/g/n
• Maximum Data Rate: 300 Mbps (2×2 MIMO)
• Transmit Power: Up to 22 dBm
• Antenna: Two internal antennas (non-removable)

Network Connectivity

• Ethernet Ports: 4x Fast Ethernet (10/100 Mbps)
• WAN Port: Port 1 (configurable)
• LAN Ports: Ports 2-4 (configurable)
• PoE Support: Passive PoE input on port 1

Physical Characteristics

• Dimensions: 113 x 89 x 28 mm
• Weight: Approximately 145 g
• Enclosure: Plastic desktop case
• Mounting: Desktop placement or wall mount

Power Requirements

• Input Voltage: 6-30V DC
• Power Consumption: Maximum 2W
• Power Adapter: 24V adapter included
• PoE Input: Supports passive PoE (8-30V)

Operating Environment

• Temperature Range: -30°C to 70°C
• Operating System: RouterOS Level 4 license
• Management: Web interface, Winbox, mobile app

Use Cases & Applications

Home Internet Router

The RB941-2nD-TC serves as an all-in-one solution for residential internet connectivity. Families connect the device to their cable or DSL modem, creating a wireless network for smartphones, tablets, and laptops throughout the home. Its built-in firewall protects against unauthorized access while parental controls limit internet access for children’s devices.

Small Office Wireless Coverage

For micro-businesses with 5-10 employees, this access point provides basic wireless connectivity in confined office spaces. The four Ethernet ports accommodate essential wired equipment like printers and desktop computers. However, the 2.4 GHz-only wireless may experience interference in crowded office buildings with numerous competing networks.

Guest Network Deployment

Businesses deploy the hAP Lite as a dedicated guest wireless network separate from primary infrastructure. Network administrators configure VLAN isolation to prevent guest users from accessing internal resources. Additionally, the device supports captive portal functionality for collecting guest information or displaying terms of service before internet access.

Remote Site Connectivity

Organizations with small remote locations like storage facilities or satellite offices use this router for basic network connectivity. The low power consumption enables extended operation on backup power systems during outages. For instance, a warehouse can provide wireless connectivity for inventory scanners without significant infrastructure investment.

Learning & Development

IT students and networking enthusiasts utilize the RB941-2nD-TC for hands-on RouterOS experience without major financial commitment. The device supports most RouterOS features found in expensive enterprise equipment, allowing practice with firewall rules, routing protocols, and network configurations. Moreover, its compact size makes it ideal for portable lab setups.
