Fanvil H603W Wi-Fi IP Phone

Overview

The Fanvil H603W is a cost-effective wireless hotel phone with multiple functions and an elegant design. It features 6 programmable soft keys for service hotlines, dual-band Wi-Fi 6, and antimicrobial materials for guest safety.

Key Highlights

• 6 programmable soft keys for service hotline access
• Built-in dual-band 2.4GHz & 5GHz Wi-Fi (Wi-Fi 6)
• Antimicrobial materials to prevent bacterial growth
• IEEE 802.11k/v/r support for fast roaming and automatic network switching
• WPA/WPA2-PSK and 802.1X EAP encryption for secure communication
• 1900mAh battery: 8.1 hours talk time, 159 hours standby
• Base supports phone fast charging up to 20W

Technical Specifications

General:

• 2 SIP Lines
• HD Voice with wideband audio
• Handset and hands-free modes
• Standard Type-C interface
• Desktop charging dock included
• Power adapter: 12V/3A

Audio Codecs:

• Narrowband: G.711A/U, G.729AB, G.723.1, G.726, iLBC
• Wideband: G.722, Opus
• Full-duplex speakerphone with AEC
• Advanced features: VAD, CNG, BNE, Noise Reduction, AGC, PLC

Wi-Fi:

• 2.4GHz: 802.11 b/g/n
• 5GHz: 802.11 a/n/ac/ax (Wi-Fi 6)
• Encryption: WPA/WPA2-PSK/802.1X EAP

Network Features:

• IPv4/IPv6 support
• VPN: L2TP/OpenVPN
• VLAN: 802.1P/Q
• QoS, LLDP support
• Multiple IP configuration options

Physical Specifications:

• Keypad: 24 keys total (12 digit keys, 6 DSS keys, 5 function keys, 1 hands-free key)
• Handset dimensions: 215×55×17.5 mm
• Base dimensions: 144.5×61.5×94.5 mm
• Color: Black
• Working temperature: 0-45°C
• Working humidity: 10-95%

Charging:

• Type-C charging port on handset
• Type-A & Type-C fast charging ports on base (up to 20W)
• 1900mAh rechargeable lithium battery
• Charging and low battery indicators

Deployment & Management:

• Auto-provisioning via FTP/TFTP/HTTP/HTTPS/DHCP/SIP PNP/TR-069
• Web management portal
• Configuration export/import
• Firmware upgrade capability
• Syslog support
